The official LM detail includes drawings for LM…UU, LM…UU-OP and LM…UU-AJ. Its parameter image separates length, retaining features, dimensional tolerances, radial clearance and load entries. For example, the LM12UU row shows length L 30 mm, the drawing’s B dimension 23 mm, dynamic C 412 N and static C₀ 598 N. Treat these as catalogue entries for the stated row, not permissible operating loads for an arbitrary installation. Actual LM drawings and table viewed in browser [2]
| Choice | Required comparison | Order decision |
|---|
| Closed UU | Shaft, housing, retention and end access | Confirm assembly procedure and controlled fits. |
| Open OP | Opening, support geometry and load direction | Check the shaft-support interface and installed orientation. |
| Adjustable AJ | Adjustment housing and specified setting | Agree clearance/running resistance and locking after setting. |
Siqiang publishes LME…UU and LMB…UU on separate pages. Preserve the complete designation and compare the actual dimensional and tolerance sheet; do not substitute among them merely because a nominal shaft description appears similar. Identify whether the order is a bare bearing, a housed unit, a flanged version or a matched shaft assembly. LME series [3] LMB series [4]
Send shaft material, hardness, finish, straightness and fit requirements together with housing bore, length, retention and alignment datums. Ask Siqiang to confirm the exact bearing/shaft pairing, applicable drawing and inspection basis.
