THE BEARINGINDEX DIRECTORY

U&J

U&J / Ningbo Youjia: a guide to four-point, non-standard and automotive bearing inquiries, connected to its actual testing-centre records.

U&J · NINGBO YOUJIA

Turn the catalogue into a controlled engineering request.

Ningbo Youjia identifies U&J as its bearing brand and describes motor, automotive and custom products. Its introduction states P4 accuracy and Z4V4 vibration capability and mentions carbonitriding for special applications. Company introduction [1] Those are manufacturer capability statements, not a declaration that every catalogue part is supplied with those properties.

Prepare a sourcing inquiry
01

Read the complete QJ designation and keep the rating units open.

The four-point-contact page lists specific models, including QJ206M, QJ208NRM and QJ307NRM/C3, alongside other QJ entries. [2] The different full designations are useful RFQ references; do not shorten them to a base number and assume the internal or locating features remain the same.

What is clear in the published table

The boundary-dimension heading uses millimetres. For example, the QJ206M row gives bore 30 mm, outside diameter 62 mm and width 16 mm. Use these as catalogue identification details, then obtain the offered part’s controlled drawing and verify its complete suffix.

What needs confirmation

The visible basic-load heading says N, but the unit basis of the decimal-valued ratings needs confirmation before calculation. This guide does not relabel them as kN or publish corrected ratings. Ask U&J to issue the current sheet with explicit units, rating basis and applicable construction.

The separate double-row angular-contact page reviewed here names the product but provides no readable numerical table. [3] It is not a substitute specification for the QJ design.

02

Mixed metric and inch tables need a single agreed drawing basis.

The custom page includes named entries such as 6201-1/2, 6202-5/8, 63/22A and 88509A, with metric/inch columns and recommended mounting dimensions. Some values/conversions or fields are visibly inconsistent or incomplete. [4] We have not repaired them silently or treated the table as a released engineering drawing.

  1. Send the actual interface

    Identify the original part and provide the mating shaft/housing drawing. Mark dimensions that cannot change, including ring widths, locating shoulders and available space. State the unit system and drawing revision.

  2. Request the offered construction

    Ask U&J to identify the proposed designation and all deviations. Confirm ring geometry, materials, closure, lubricant and clearance. Where a special process such as carbonitriding is proposed, ask which components and specification it covers.

  3. Approve measurable conditions

    Agree the critical dimensions, running requirements and installed test. Record the offered sample’s drawing/material/process revision and the changes that need notice before serial delivery. A “non-standard” category does not approve every requested design.

03

Choose the report that answers your component’s risk.

The testing-centre pages name spectroscopy, length and roughness measurement, cleanliness analysis, life testing, heat-treatment metallography, high/low-temperature endurance and programmable salt-spray equipment. [5] [6] [7] These are manufacturer-published facilities, not passing results for your selected bearing.

Material or heat-treatment requirement

Request the specified material, relevant process record and the report for the approved part or lot. Agree sampling and acceptance criteria; a spectroscopy or metallography listing alone does not establish the material of a quoted variant.

Contamination or environmental exposure

Define cleanliness, temperature and corrosion concerns using the actual environment. Ask which test method, duration and specimen condition will apply. Do not turn a salt-spray equipment listing into a universal corrosion-life promise.

Automotive component inquiry

The official alternator page names that product route but does not provide a complete readable part specification. [8] Send the alternator/component drawing and customer acceptance requirements. Identify exact location, lubricant, closure, duty and traceability; do not infer vehicle-model interchangeability or customer approval.

A government-hosted 2024 enterprise technical R&D-centre recognition list names Ningbo Youjia as the supporting entity for the Youjia precision-bearing centre. [9] This cross-checks the centre recognition; it does not establish laboratory accreditation or validate a particular report.

04

A dated plasticiser policy is a starting document, not a current product test.

The official plasticiser statement is labelled U&J 201604/PLS, Issue 1, April 2016. It lists DEHP, DBP, DIBP and BBP and names Ningbo U&J Bearing Manufacturing Co., Ltd. at No. 26 Lujiafan Road, Langxia, Yuyao. [10] The current Chinese company introduction/footer uses 宁波友嘉轴承有限公司 and the same street address. [1] Confirm the legal name used for the quotation and test documents rather than assuming English renderings establish different factories.

For restricted-substance procurement, ask for the current declaration, covered parts/materials, applicable requirement and any required supporting test. The 2016 policy is not a present batch-specific conformity report. Similarly, the company’s quality/environment/safety system statements need current issuer, validity and site-scope checks if required by your project.

Do the homepage honours qualify the bearing?

No. Separate company or factory recognition from the proposed product’s material, dimensions, running properties and approval records. This review has not established a current “green factory” certificate scope or assessed all of the homepage honours.

YOUR NEXT STEP

Prepare a U&J drawing-and-evidence request.

Tick what you have ready. Copy the full checklist with its current status for your procurement notes.

Checks stay in this page and reset on reload. Nothing is sent to the manufacturer. The inquiry link opens a separate form.

Materials to prepare
Continue to sourcing inquiry →

Documented models.

0 model records

No documented models yet.

Try broader requirements, or explore the manufacturer’s published product scope.

Explore manufacturers →

Evidence, with boundaries.

Our review approach →

Facts above are attributed to their source. Buying and qualification steps are BearingIndex editorial suggestions. Sources checked ; this is not the sources’ publication date or an independent factory audit.

  1. Manufacturer publicationU&J · Ningbo Youjia company introduction ↗

    Brand/entity/address and stated P4/Z4V4, special-process and quality-system capabilities; no universal model guarantee or current certificate verification.

  2. Manufacturer numerical catalogueU&J · four-point-contact catalogue ↗

    QJ designations and mm boundary dimensions; basic-load unit basis needs confirmation, so no corrected ratings published.

  3. Manufacturer product pageU&J · double-row angular-contact page ↗

    Product route; no readable complete numerical specification obtained.

  4. Manufacturer numerical catalogueU&J · non-standard designs ↗

    Named designs and metric/inch/mounting columns; inconsistent or incomplete entries are not silently corrected.

  5. Manufacturer facility publicationU&J · testing centre, page 1 ↗

    Material/dimensional equipment and centre statements, not an accredited lab scope or passing order report.

  6. Manufacturer facility publicationU&J · testing centre, page 2 ↗

    Cleanliness, life and metallography equipment listing; methods and acceptance remain order-specific.

  7. Manufacturer facility publicationU&J · testing centre, page 3 ↗

    Temperature-endurance and salt-spray equipment, not a general performance guarantee.

  8. Manufacturer product pageU&J · automotive alternator bearing ↗

    Named automotive product route; no vehicle cross-reference, customer approval or complete part specification obtained.

  9. Dated government recordNingbo · 2024 enterprise technical R&D-centre recognition list ↗

    Youjia precision-bearing R&D-centre recognition and supporting company; not laboratory accreditation or product certification.

  10. Dated manufacturer policyU&J · plasticiser policy, Issue 1 April 2016 ↗

    Named substances, English company identity and address; not a current part/batch test or present certificate verification.

Report a source correction → · Return to inquiry checklist ↑

U&J published product scope reviewed

The manufacturer website describes motor and automotive auxiliary bearings.

Scope: Official website product scope only. No independent factory audit, material-report review or model-level performance validation is implied.

Company-level record; not a model test report · 2026-09-24 04:20:33

Source documentation retained for editorial review.
