FSM / Quanzhou Huayang makes mounted insert-bearing units and housings. Its UCP, HCP and UKP installation pages identify set-screw, eccentric-collar and adapter-sleeve arrangements separately. Specify the shaft lock, metric/inch bore and housing envelope together; the catalogue family is not a complete replacement specification.
Choose the shaft lock before approving the complete housing unit.
Quanzhou Huayang Bearing Co., Ltd. (泉州华洋轴承有限公司) identifies FSM as its trademark and mounted insert bearings and housings as its focus. The official site provides three distinct mounting routes: UCP with set screws, HCP with an eccentric collar, and UKP with an adapter sleeve. Order the actual insert, lock and housing combination rather than a photograph of a similar unit. Company and product scope [1]
UCP, HCP and UKP need their own mounting and accessory specification.
| Actual official route | Confirm before buying | Installation evidence |
|---|---|---|
| UCP — inner-ring set screws | Exact bore, shaft tolerance/surface, screw access and supplied insert/housing. | Selected-part screw specification and approved tightening procedure. UCP page [2] |
| HCP — eccentric collar | Collar/shaft interface, available clearance and intended rotation/reversing duty. | Selected-unit locking direction, collar/screw procedure and application approval. HCP page [3] |
| UKP — adapter sleeve | Bearing/sleeve designation, shaft interface and sleeve/nut/locking-device inclusion. | Mounting adjustment/clearance instructions and disassembly access. UKP page [4] |
The official pages explicitly distinguish these arrangements. Do not transfer a generic tightening torque or mounting sequence across them. Ask the engineer to approve the actual shaft fit, locking components, housing seating and speed/load duty. A housing family name does not identify all components included in the quotation.
Read the complete bore designation and the housing drawing together.
The actual UCP200 illustrated table separates metric and inch entries: UCP205 is shown with a 25 mm shaft bore, while UCP205-16 is the 1-inch version. A close-looking designation does not permit substituting the shaft size. Request the current controlled drawing for the complete suffix. Actual UCP200 drawing/table [5]
Measure the existing mounting
Provide shaft diameter, centre height, base envelope, bolt/slot spacing and mounting surface. Record alignment, adjustment/retention arrangement and space for locking, lubrication and removal.
Freeze the supplied assembly
Confirm insert and housing codes/materials, lock/accessories, seals, grease and lubrication fittings. The official UCP drawing labels SR and TRL seal forms; ask which form the offered suffix actually includes.
The homepage lists UCF, UCFL/HCFL, UCFB, UCT/UCST and UCC families separately. Select flange, take-up or other mounting architecture from the actual machine interface. Do not infer structural limits or a matching bolt pattern from a similar photograph. The site's displayed 0.00 prices are not a real quotation. Actual catalogue and displayed prices [1]
Keep the government project and supplier output claims in their own scope.
The Quanzhou environment authority's November 2023 EIA document-quality table lists Huayang's 200-tonne annual mounted-bearing project, approved 1 November 2023, document 泉南环评〔2023〕表225号, at Meishan Industrial Area No.23. This is a dated project record, not a current available-output receipt. Its tonnes cannot be equated with the homepage's supplier claim of more than two million bearing sets annually. Actual government PDF, row37 [6] Supplier production statement [1]
- Technical offer: freeze full unit drawing, metric/inch bore, locking arrangement, housing and seal/lubricant.
- Manufacturing responsibility: confirm who makes castings/housings, inserts and final assembly, and which steps are outsourced.
- Traceable sample: agree material/dimensional evidence, locking and installed running acceptance under representative duty.
- Repeat lots: retain lot inspection, approved component sources and written change controls.
Provide load direction/magnitude, speed, vibration, alignment, temperature, contamination and washdown/media where relevant. Obtain the selected unit's limits, lubrication schedule and installation instructions. The site's general “international certification” or industry-solution language does not identify a current certificate, selected-model test or machine programme approval. Request the actual entity/site/scope evidence required by the buyer. Official claims and application headings [1]
Confirm the address wording and the quotation owner.
The official contact lists Mr Li, 13859764176, [email protected], fax 0595-86580022, and No.23, Xinlan Industrial Area, Meishan Town, Nan'an, Quanzhou. The website writes 新蓝 and the government project writes 新兰. Confirm the exact manufacturing/audit and receiving location rather than silently treating a spelling difference as proof of a relocation. Official contact [7] Government project address [6]
Request the legal contracting/payee name, exact configuration, sample and serial quantities, available stock, agreed lead time, packing/corrosion protection and delivery terms. Separate insert-only, housing-only and complete-unit offers, and list collar/sleeve/nut/locking-device inclusion. A product listing or annual production claim does not reserve stock or capacity.
Keep lot markings, mounting measurements, lubrication and operating records for service claims. Before repeat orders, approve any change to housing, insert source, seal, grease or locking hardware against the original release.
