Boundary dimensions · schematic, not a product photograph or manufacturing drawing.
Deep groove ball
16005
16005 is a deep groove ball designation documented on BearingIndex from 5 manufacturer publications. The published boundary dimensions are 25 × 47 × 8 mm. The publishing works are in Zhejiang province, China. Every value below comes from that manufacturer’s own published material, with the date it was recorded.
Global’s 16005 has more balls than its 6005. Does that make it stronger?
The actual catalogue rows say otherwise for the published load ratings: 16005 lists 12 balls and Cr = 6940 N, while 6005 lists 10 balls and Cr = 10060 N. Compare ball size, envelope and the selected duty; ball count is not a capacity or quality score.
The additional balls accompany a smaller ball size and a narrower bearing.
16005 has two more balls, yet its published dynamic rating is 3120 N lower and its static rating is also lower. The ball-count claim therefore cannot justify a higher published capacity for this item. That difference is not an allowable machine-load reduction or a measured service-life result.
The catalogue supplies ball size as well as count, but does not explain the rating difference through a controlled internal-design comparison. This guide does not attribute it to steel quality, cage quality or a single geometric cause.
The narrower envelope may solve a space problem; it still needs a load and drawing review.
Moving from the listed 6005 to 16005 reduces nominal width by 4 mm while retaining the 25 mm bore and 47 mm outside diameter. Identify whether that space reduction is the actual requirement. If the reason for substitution is increased load rating, these rows do not support it.
For a space-driven change, redraw the actual locating and retaining stack for the selected width. The bearing chamfer entries also differ: obtain the selected item’s mating-shoulder and corner limits instead of assuming the old 6005 drawing remains applicable. Neither nominal envelope establishes an unchanged fit or mounting approval.
For load selection, supply the bearing-position forces and required duty to Global and request an assessment for the full offered 16005 designation. A catalogue rating is not the application’s actual operating load. For speed, request Global’s 16005 construction-specific evidence: its examined metric table has no speed column, so the 6005 values cannot fill that gap.
This page freshly examines Global’s two actual rows. Other manufacturers’ historical 16005 records in the directory are not merged into this comparison. A quote from another maker requires its own complete rating, drawing and operating evidence.
A dash means the site’s recorded data does not provide that value; it is not proof that the manufacturer has never published it. Check the reviewed source notes for any newer findings. Dimensions every source agrees on are shown above rather than repeated per row.
Compare the recorded figures.
Property
Finding
Sources
Dynamic load rating
Ranges 6.94 – 8.85 kN across 3 sources
3
Static load rating
Ranges 4.6 – 5.63 kN across 3 sources
3
Limiting speed — grease
Ranges 13000 – 15000 rpm across 3 sources
3
Limiting speed — oil
Ranges 16000 – 18000 rpm across 3 sources
3
Reference mass
All 2 sources publish 0.059 kg
2
Where the figures differ, use the drawing from the manufacturer you buy from.
Calculated from the published values.
Figure
How it is obtained
Result
Radial section height
(D − d) / 2
11 mm
Mean diameter dm
(D + d) / 2
36 mm
C / C₀ load ratio (3 sources)
dynamic ÷ static load rating
RCL 1.57 · NBK 1.51 · INYOUNG 1.58
Arithmetic on the figures above — not a bearing life calculation for your load case.
CZ publishes more than a series list: endurance examples, seal/torque comparisons, thermal considerations and Ppk/Cpk targets. Use those details to define the trial for your motor, keeping a 6205ZZ fatigue example separate from the unnamed high-speed endurance test and requesting current part-linked reports and certificate scope.
Published ranges: Metric miniature motor bearings · Inch R-series bearings · Stainless steel bearings · Nonstandard bearing designs
72 designations documented here · 1 reviewed evidence record · source recorded 2026-10-08
INYOUNG publishes ball and roller bearing families from Wenling. Its deep-groove tables show why bore size alone is insufficient for replacement, while its material pages distinguish bearing-steel and stainless options. Obtain the current model drawing and confirm the offered material, closure and lubrication; online access limitations and catalogue inconsistencies remain unresolved.
Published ranges: Deep groove ball bearings · Cylindrical and tapered roller bearings · Spherical roller bearings · Angular contact bearings
93 designations documented here · 1 reviewed evidence record · source recorded 2026-10-08
NBK’s actual 5200 and Q523 pages separate dimensions, tolerance fields, steel/Si3N4 ball options and grease/oil speeds. Its ceramic route is a steel-ring hybrid proposal, not an all-ceramic corrosion or temperature guarantee. Reconcile actual in-house/outsourced manufacturing with the offered order; ISO9001 and ISO14001 queried valid on2026-10-08, while the displayed IATF image expired in2025 and requires a current record.
Published ranges: Deep groove ball bearings · Customer-specific nonstandard bearings
32 designations documented here · 1 reviewed evidence record · source recorded 2026-10-08
RCL publishes 67/68/69, MR and 16 thin-section families and a harmonic-reducer bearing page. Its 67-series description explicitly asks designers to consider load capacity; encoder and flexible-bearing applications need different qualification inputs.
Published ranges: 67- and 68-series thin-wall bearings · 69-series ball bearings · 60-series ball bearings
131 designations documented here · 1 reviewed evidence record · source recorded 2026-10-08
Global publishes ordinary shielded/sealed bearings alongside nonstandard steel and polymer pulley assemblies. Its scanned catalogue provides useful part-specific dimensions and construction examples; distinguish bore from shaft dimensions, match the complete assembly drawing, and confirm lubricant, noise testing and the current contracting entity.
Published ranges: Miniature and small bearings · Rubber-sealed bearing designs · Metal-shielded bearing designs
71 designations documented here · 1 reviewed evidence record · source recorded 2026-10-08
Application areas each manufacturer states for its own range. Confirm load, speed, temperature and lubrication for your case.
Fields absent from the recorded dataset.
Precision class · Internal clearance · Sealing · Material · Cage material · Z class · V class · Limiting speed · Lubrication · Operating temperature · Precision standard · Ring material · Rolling element material · Noise / vibration test method · Manufacturer series · Manufacturer suffix · Ball count · Ball diameter.
PDF page 7, printed page 11, full headers and enlarged exact row viewed: 12 × 5.963 mm balls, dimensions, N ratings, chamfer and mass. No speed column.
PDF page 6, printed page 9, full headers and enlarged exact row viewed: 10 × 6.35 mm balls, dimensions, 10060/5860 N, chamfer, grease/oil speeds and 0.080 kg mass.
Guide checked 2026-10-09. Manufacturer statements, technical background and BearingIndex purchasing suggestions are distinguished in the text. This is not application approval or firsthand product testing.
